To a stirred solution of 4 (220 mg,
0.5 mmol, 1.0 equiv) in dry toluene (20 mL) was added a solution of PhSH (76
µL, 0.75 mmol, 1.5 equiv) and AIBN (24.6 mg, 0.15 mmol, 0.3 equiv) in dry
toluene (10 mL) at temperature ranging
from 60°C-120°C (entries 1-4) under argon atmosphere in a dropwise manner by
a syringe pump over 3h. Another solution of PhSH (76 µL, 0.75 mmol, 1.5
equiv) and AIBN (24.6 mg, 0.15 mmol, 0.3 equiv) in dry toluene (10 mL) was
added to the solution at the same temperature in a dropwise manner over an
additional 3h. After completion, the mixture was cooled to ambient temperature
and the solvent was removed under vacuum and the residue was purified by a
flash column chromatography on silica gel (hexane/EtOAc = 10:1) to give
product 3 as a colorless oil at a 35% yield.
To identify reaction parameters including thiyl
radical precursor, radical
initiator, solvent, and temperature, further experiments with variable
parameters were carried out. Because of the thermal instability of the
vinylcyclopropane moiety in 4, in a separate procedure, the resultant reaction
mixture containing 4, PhSH, and AIBN was stirred at room temperature under UV
irradiation for 5h. Purification process remained the same as in the general
procedure to yield 32%. Then, AlMe3 was used as a Lewis Acid in a separate
synthesis of 3 from 4, increasing the yield to 40-48%. To test the key annulation
reaction in the presence of transition-metal catalysis under visible light, the
solvent toluene was replaced with MeCN (5 mL) and several commercially available
catalysts were added to reaction. The use of catalyst Ir(dF(CF3)ppy)2(dtbbpy)PF6
provided 3 at the highest yield of 50% under irradiation with low-energy blue
light-emitting diodes (LEDs).
Synthesizing a molecule is like painting a masterpiece. The experimental above guides you to the miraculous molecule 3. Follow along so your chemical masterpiece won't be tossed in the hazardous waste along with Squidward's painting!
